Details
What Makes it a P8i?
- Bosch Active Line Plus motor provides up to 50 Nm of torque and 270% support
- Bosch PowerPack 400 powers long trips, commutes, and journeys
- Shimano Nexus 8-speed internal hub
- Shimano hydraulic disc brakes for reliable stopping power-even when carrying cargo and riding fast
NBD Highlights
- Ultra-low 39 cm (15.4") standover height means gentle, low steps are all that's required to get on and go
- Ultra-low center of gravity improves balancing and maneuvering when riding with kids through parks and narrow streets
- Fits riders 147—190 cm (4'10"—6'3")
- Gaia Rack is certified to carry up to 27 kg (60 lbs) and works with many child seats
- Proven safe and reliable: frame and fork have undergone the EFBE Tri-Test to the 140 kg (309 lbs) Maximum Gross Vehicle Weight
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Specs
Frame | Tern NBD, 6061-AL, Patented design, EFBE Tri-Test approved: 140 kg |
---|---|
Fork | Tern Tarsus, 6061-AL, hydroformed, EFBE approved: 140 kg |
Rims | Kinetix Comp, for disc |
Hubs | Shimano Disc |
Spokes | Stainless Steel |
Tires | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
Bottom Bracket | Motor integrated |
Crankset | Tern NBD custom, forged 6061-AL crankarm |
Shifters | Shimano 8 spd. |
Rear Derailleur | Shimano Nexus 8 |
Cassette/Freewheel | 16T |
Chain | KMC for eBike, EPT corrosion resistant coating |
Brakes | Shimano, hydraulic disc |
Brake Levers | Shimano, hydraulic disc |
Handlebars | Tern Sweep, 6061-AL, Tern Andros adapted |
Tape/Grips | Ergon |
Stem | Tern Andros, adjustable, forged construction, patented technology |
Headset | Tern Flux by FSA, cartridge bearings, Physis integrated |
Seatpost | Tern RideEasy Suspension, 34.9 mm, Air cartridge, Preload adjustable |
Saddle | Tern Upright by Velo |
Pedals | MKS Platform, Tern custom design |
Accessories & Extras | BELL: Aluminum CHAINGUARD: Tern Custom, full chain cover KICKSTAND: Ursus, rear mount LUGGAGE SOCKET: Combo Mount FRONT LIGHT: Tern Valo Direct, 190 lumens REAR LIGHT: Herrmans FENDERS: SplashGuard, stainless hardware RACK(S): Gaia Rack, 27 kg capacity, Vertical Parking FRAME LOCK: ABUS, keyed-alike with Bosch battery |
Motor | Bosch Active Line Plus, 270% Assist, 50 Nm Torque, max speed 20 mph (US) |
Battery | Bosch PowerPack 400 |
Controller/Display | Bosch Intuvia, 4 mode selectable, walk assist |
Charger | Bosch Standard Charger |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Red / One Size | 810067160018 | 12-91-02 | |
Silver Blue / One Size | 812741029987 | 12-91-01 | 210000030006 |
